FR4 Laminate
Drill Entry and Backup sheets
Inks for PISM, UV curing, legend, etc
  • Low CTE with excellent thermal resistance
  • Tg 150(DSC)
  • High thermal decomposition temperature (Td)
  • Lead-free process compatible
  • Extremely robust, good for high reliability board

  • Multifunctional Epoxy Resin
  • Tg 175 (DSC)
  • Low Z-axis Coefficient of Thermal Expansion
  • Excellent Dimensional Stability and heat resistance
  • Low Water Absorption
  • Good Drilling Properties
  • Processing Like IT140
  • UL 94 V-0
  • AOI and UV blocking characteristic

Set new standards for phototool production with KODAK ACCUMAX Photoplotter Film ABG7. This advanced film delivers superb image quality and line sharpness with raster imaging photoplotters that use blue-green laser light sources.

  • Extremely high contrast, blue/green sensitive film.
  • Designed to produce high quality phototools on raster imaging photoplotters, and other artwork generators with output at 488, 532, 543, and 565 nanometres.
  • High photographic speed for longer laser life.
  • Dimensionally stable emulsion.
  • Excellent scratch and abrasion resistant overcoat
  • Coated on a dimensionally stable ESTAR Base with antistatic and surface properties to ensure dependable transport and handling behavior. This property also helps to resist attraction of dirt and dust.
  • Excellent line-edge acuity for critical phototools.
  • Contains ultra-fine matte on the emulsion side to improve handling and vacuum draw-down to photo resist
  • Excellent reciprocity characteristics for dependable photoplotting performance.
  • Can be handled under light red (series 1A) safelight.
  • Recommended for processing in KODAK ACCUMAX Rapid Access Developer and Replenisher.
  • CANNOT be processed in lith or KODAK ULTRALINE Developer and Replenisher


Creating high-complexity phototools starts with the right film. Now from Kodak, you get a hard, line-edge quality and good dimensional stability with KODAK ACCUMAX Photoplotter Film RED7. RED7 Film uses the latest Integrated- Booster-Technology (IBT processing)— technology pioneered by Kodak. Some of its outstanding features include:

  • Extremely sharp line-edge quality, with the latest in Integrated Booster Technology processing, recommended for processing in IBT compatible developers such as KODAK ACCUMAX Rapid Access Developer and Replenisher.
  • Suitable for lines and spaces as small as 1 mil and photo plotter resolution settings as high as 12,000 DPI.
  • Rapid processing, as fast as 30 seconds development time, for high productivity
  • Matte is on the emulsion side, to provide rapid draw-down to photoresist
  • Excellent resistance to photo abrasion and physical wear
  • Permanent anti-static performance to resist the attraction or dust and dirt
  • Dual red sensitivity at 633 nm and 670 nm for use with photoplotters using helium-neon(HN) or red-laser-diode (RLD) exposing sources.
  • Very good line reproduction on photoresist.
Aluminum Entry Sheet (A1100H18)
    Use: special alloys optimized for use as drill entry boards
    Thickness: 0.14mm-0.20mm
    Thickness Tolerance: ±10%
    Size Tolerance: ±3mm
    Warpage: =<1%of diagonal
    Roughness: 3.5µm±1µm
    Standard Size: 36"*48";40"*48";42"*48" 37"*49";41"*49";43"*49"

  • Good protection of the sheet free CCL from scratches and pressing marks.
  • Excellent guides to high speed drilling when drill bit touch the surface.
  • Good conduct or character and good cleaning of the drill can greatly extend drill's life and avoid oxidation of the surface.
  • Permanent anti-static performance to resist the attraction or dust and dirt
  • Dual red sensitivity at 633 nm and 670 nm for use with photoplotters using helium-neon(HN) or red-laser-diode (RLD) exposing sources.
  • Burr-free drilling and excellent hole wall quality.

White Melamine Wood Backup Board(WM27;WM25;WM20;WM15)
    Use: It specially manufactured for nice drilling.
    Thickness: 2.7mm/2.5mm/2.0mm/1.5mm
    Thickness Tolerance: ±0.15mm
    Size Tolerance: ±3mm
    Density: 930kg/m3 and above
    Hardness: 75±5shores D
    Warpage: less than 0.6% of diagonal
    Standard Size: 37"*49"; 41"*49"; 43"*49"

  • WM boards were made from high density wood fibre boards and melamine papers.
  • The wood Boards were laminated with melamine papers under high-pressure and high- temperature.
  • Good performances of WM boards make itself replace conventional penolic boards to perform high tech drilling.
  • Reduced drill wear.
  • Reliable qualities reduce loss in the production
  • Environment friendly.

Wood Backup Board (BW & BU series)
    Thickness: 2.5mm
    Thickness Tolerance: ±0.15mm
    Size Tolerance: ±3mm
    Type£º : BW Series-HDF, BU Series- MDF
    Density: BW Series 850kg/m3 and above, BU Series 800kg/m3 and above
    Hardness: 70±5 Shores D (BW),60±5 Shores D (BU)
    Warpage: less than0.6% of diagonal
    Standard Size: 37"*49";41"*49";43"*49"; 36”x48” & so on

  • Good performance and low price.
  • Excellent flatness and thickness tolerance.
  • Environmental friendly.

We offer a full range of liquid resists for use in the Printed Circuit Board manufacturing industry and other industries that chemically etch metals. We also have an extensive range of conductive inks.

  • Imagecure LPI Solder Mask
  • Halogen Free
  • Laser Direct Imaging
  • Hole Plug
  • Screen Defined resists and Coverlay
  • Etch and Plating Resists
  • Flexible resists and coverlays
  • Peelables
  • Conductives
  • Printed Heater Products
  • Notation Inks
  • Solvents
  • ROHS/WEEE Directives
